Teltonika FM6300 (3G)

Heavy transport tracking device on 3G networks

Teltonika FM6300 (3G)
Teltonika FM6300 (3G)
Teltonika FM6300 (3G)
Teltonika FM6300 (3G)
  • Free worldwide shipping
  • No contracts
  • 2 years warranty
$149
Quantity - +
Total: $

Description

Teltonika FM6300 is GNSS, 3G terminal for PROFESSIONAL applications. FM6300 is designed for complex solutions, where one device can do multiple tasks. 3G feature makes this device usable worldwide. FM6300 features like FMS CAN data (J1939), fuel CAN data (J1708), tachograph live data (K-Line), remote tachograph file download, various third party RS232 or RS485 devices support and Dual-SIM will maximize your fleet efficiency. Terminal is suitable for applications like international logistics, refrigerated transport, agriculture, construction & mining, security & emergency services and even more.

3G

It makes this device usable worldwide, as there are countries which have only 3G network. Device automatically selects available network (3G or 2G) to ensure the best connectivity in area.

Dual SIM

Double GSM network reliability with Dual SIM! Even if your main SIM card fails to connect, FMB640 will stay online. Moreover, Dual SIM significantly reduces roaming costs, when using first SIM card for Home, second for Roaming data networks.

Internal battery

Feel safe when vehicle is monitored by device with internal battery. When vehicle battery is disconnected, device still remains online and sends data to server.

RS232/RS485

RS232/RS485 functionality enables connection of third party devices like: multiple LLS sensors, GARMIN personal navigation device, RFID readers or some other RS232/RS485 devices.

Integrated tachograph solution

Integrated tachograph solution enables remote tachograph file (DDD, V1B, C1B or TGD format) download and live tachograph info acquisition without any additional adapter. Easier than ever connection – less integration time.

Specification

Module
Name Quectel UC20-G
Technology GSM/GPRS/3G
GNSS
GNSS GPS, GLONASS, GALILEO, QZSS
Protocol compatible NMEA, GGA, GGL, GSA, GSV, RMC, VTG
Receiver 32 channel
Tracking sensitivity -162 dBM
Accuracy < 3 m
Hot start < 2 s
Warm start < 25 s
Cold start < 33 s
Cellular
Technology GSM/GPRS/3G
UMTS/HSPA+ bands 800/850/900/1900/2100MHz
GSM/GPRS/EDGE bands 850/900/1800/1900MHz
EDGE/GPRS Multi-slot Class 12
Data transfer GPRS data downlink/uplink up to 85.6 Kbps, UMTS data downlink/uplink up to 384 Kbps, EDGE data downlink/uplink up to 236.8 Kbps, HSPA+ data up to 5.76 Mbps uplink, HSPA+ data up to 14.4 Mbps downlink
Data support SMS (text/data)
Power
Input voltage range 10 - 30 V DC with overvoltage protection
Back-up battery 550 mAh Ni-Mh, 8,4 V battery
Power consumption At 12V < 7 mA(Deep Sleep), At 12V < 12 mA(Online Deep Sleep), At 12V < 28 mA(GPS Sleep), At 12V < 65 mA(nominal), At 12V <120 mA (GPRS)
Interface
Digital Inputs 4
Digital Outputs 4
Analog Inputs 3
1-Wire temperature sensors 6
1-Wire iButton 1
RS232 2
RS485 1
CAN j1939 2
J1708 1
K-line 1
LVCAN 1
GNSS antenna External High Gain
GSM antenna External High Gain
USB 2.0 Mini-USB
LED indication 2 status LED lights
SIM 2x SIM Card (Dual-SIM)
Memory 1MB internal flash memory and external Micro SD card
Physical specification
Dimensions 104,1 x 76,8 x 31,5 mm (L x W x H)
Weight 197 g
Operating environment
Operating temperature -25 °C to +55 °C
Storage temperature -40 °C to +70 °C
Operating humidity 5% to 95% non-condensing
Ingress Protection Rating IP41
Features
Sensors Accelerometer
Scenarios Green/Eco Driving, Over Speeding detection, Jamming detection, Excessive Idling detection, Towing detection, Crash detection, Immobilizer, iButton Read Notification.
Functionalities Auto Geofencing, Manual Geofencing, Trip detection, Odometer, Fuel counter, GNSS Unplug Detection, DDD download and Tacho online data, Offline tracking, Profiles
Supports Garmin, RFID RS232, RFID 1-Wire, iButton 1-Wire, Temperature 1-Wire, MVC300 camera, LV-CAN, ALL-CAN, CAN FMS (J1939, J1708), K-Line data
Sleep modes GPS Sleep, Online Deep Sleep, Deep Sleep
Configuration and firmware update FOTA, USB cable
SMS Configuration, Events, DOUT control, Debug
GPRS commands Configuration, Events, DOUT control, Debug
Time Synchronization GPS, NITZ, NTP
Fuel monitoring LLS (Analog), LV-CAN, ALL-CAN, CAN FMS, RS232/485 Fuel sensor
Ignition detection Digital Input, Accelerometer, External Power Voltage
Certification & Approvals
Regulatory Declaration of IMEI assignment

Use cases

International Logistics

Modern day logistics require a lot of information for business optimization, it is not enough to get current GPS coordinate of your vehicle location. With fuel consumption, driven distance and many other parameters you are able to monitor and regulate your fleet resources, this way all expenses would be accounted. With solution for driver activities monitoring you will have full control of your driver.

Security & emergency services

Concept of public security has changed significantly in the past decade. Safety of our society depends on technology which allows us to monitor, track and respond to emergency calls faster than ever. With our solution you will always know current location and status of your transport, thus ensuring quick response time to any kind of situation.

Construction & mining

Probably most important aspect of construction machinery management is fuel consumption data. Powerful cranes and high capacity concrete mixers compared to light vehicles, use huge amounts of fuel during short periods of time – high chance of fuel theft if work time is accounted only on paper. Take full control of your fleet, workers and resources.

Public transport

Public transport requires a lot of management. It is always important to know where vehicles are, how long they drive and rest – all this to achieve best efficiency. With fuel data and other various parameters you are able to monitor and control your fleet resources, thus cutting expenses to minimum. With solution for driver or even passenger monitoring you will have full information about people who were using your transport.

Agriculture

Agricultural machinery has advanced a lot in recent years, technology like modern tractors or harvesters usually costs more than a sports car – it is essential to keep track of such valuable assets. With our solution you will have full control of current position, driver activities and receive various information from harvesting machinery.
