Teltonika FMB204 (All-in-one Package)
Small and professional tracker
*Subscription includes GPS tracking software, mobile app and SIM with cellular data service with nearly worldwide roaming (full list of supported countries here).
$0
All-in-one Package RECOMMENDED
Teltonika FMB204
$0
Software + APP + SIM (with data plan)*
$12.42 / month
Quantity
-
+
Total for 12 months:
$
(paid every 12 months)
Description
Teltonika FMB204 is a SPECIAL waterproof (IP67) tracker with Bluetooth connectivity, internal high gain GNSS and GSM antennas and integrated high capacity backup battery. Device is designed to work longer without power supply. FMB204 with LiPo battery can work up to 6 days in power saving mode. FMB204 is perfectly suitable for agriculture, delivery, refrigerated transport, trailers tracking, security & emergency services and even more. 6-30V power supply makes FMB204 suitable for motorbikes and water transport.
Specifications
| Module | |
| Name | TM2500 |
| Technology | GPRS+GPS+BLUETOOTH |
| GNSS | |
| GNSS | GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS |
| Receiver | Tracking: 33/99 acquisition channels |
| Tracking sensitivity | -165 dBM |
| Accuracy | < 3 m |
| Hot start | < 1 s |
| Warm start | < 25 s |
| Cold start | < 35 s |
| Cellular | |
| Technology | UMTS/HSPA+, GSM/GPRS/EDGE |
| 2G bands | Quad-band 850 / 900 / 1800 / 1900 MHz |
| 3G bands | 850 / 900 / 1700 / 1900 / 2100 MHz |
| Data transfer | HSPA+ uplink up to 5,76 Mbps, downlink up to 14.4 Mbps, UMTS uplink/downlink up to 384 Kbps, EDGE uplink/downlink up to 236.8 Kbps, GPRS and EDGE class 12 |
| Data support | SMS (text/data) |
| Power | |
| Input voltage range | 10 - 30 V DC with overvoltage protection |
| Back-up battery | Li-Polymer rechargeable battery, 3.7 V, 170 mAh |
| Power consumption | At 12V < 2,2 mA (Ultra Deep Sleep), At 12V < 4,5 mA (Deep Sleep), At 12V < 5 mA (Online Sleep), At 12V < 12 mA (GPS Sleep), At 12V < 35 mA (nominal) |
| Blue-tooth | |
| Specification | 4.0 + LE |
| Supported peripherals | Temperature and Humidity sensor, Headset |
| Interface | |
| Digital Inputs | 1 |
| Digital Outputs | 0 |
| Analog Inputs | 0 |
| GNSS antenna | Internal High Gain |
| GSM antenna | Internal High Gain |
| USB | Micro USB socket |
| LED indication | 2 status LED lights |
| SIM | Micro-SIM |
| Memory | 128MB internal flash memory |
| Physical specification | |
| Dimensions | L(50,7mm)xW(49,6mm)xH(25mm) |
| Weight | 63 g |
| Operating environment | |
| Operating temperature | -25 °C to +55 °C |
| Storage temperature | -40 °C to +70 °C |
| Operating humidity | 5% to 95% non-condensing |
| Ingress Protection Rating | IP41 |
| Features | |
| Sensors | Accelerometer |
| Scenarios | Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip |
| Sleep modes | GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep |
| Configuration and firmware update | FOTA Web, FOTA, FMB Configurator (USB, Blue-tooth), FMBT mobile application, BTAPP mobile application |
| SMS | Configuration, Events, Debug |
| GPRS commands | Configuration, Debug |
| Time Synchronization | GPS, NITZ, NTP |
| Fuel monitoring | OBD II |
| Ignition detection | Accelerometer, External Power Voltage, Engine RPM |
| Certification & Approvals | |
| Regulatory | FCC, E-Mark, RoHS, REACH |
| GSM/GPRS/GPS/BLUETOOTH |
